Passive Components

INTECH is proud to present its newest series of passive combining system to the market. The CMB-2x602-FM is a 10kW FM hybrid combiner , with nr.2 pluggable 7/8" input connectors and 1"-5/8 output connector. The dummy load connection in performed by a 7/16 connector.

INTECH is proud to present its newest series of passive combining system to the market. The CMB-4x502-FM is a 50kW FM in phase combiner , with nr. 4 pluggable 7/8" input connectors and 3"-1/8 output connector. The dummy load connections are performed by three 7/16 connectors.

INTECH is proud to present its newest series of passive combining system to the market. The CMB-8x602-ISM is a 50kW progressive combiner, at the frequency of 352,25Mhz for scientific application. With nr.8 pluggable 7/8" input connectors and 4"-1/2 output connector. The dummy load connection in performed by nr.8 pluggable 7/8" connectors as well. The innovative design allow to combine 8 modules of 6kW eack in a single rack.

The CMB-3x503-ISM is a 125kW progressive combiner, at the frequency of 352,25Mhz for scientific application, with three 4"1/2 input connectors and 6"-1/8 output connector. The dummy load connection in performed by two liquid cooled dummy load (optional ) with 3"1/8 connectors. The innovative design allow to combine 3 19" racks with 50kW output power each into a 125kW output amplifier.
